IMU – Inertial Measurement Unit (CAN)

Inertial Measurement Unit (IMU) measures acceleration and angular rate for all three orthogonal axes and outputs the data via CAN.

Specification:

• Acceleration Measurement Range ±2 / ±4 / ±8 (default) / ±16 g
• Angular Rate Measurement Range ±245 (default) / ±500 / ±2000 dps
• Acceleration Accuracy < 1% FS
• Angular Rate, Accuracy < 1.5% FS
• Sampling Frequency & Bandwidth 10 / 50 / 120 / 240 (default) / 480 Hz

Strain Gauge Amplifier (CAN)

Key Features

• 24-Bit ADC-to-CAN Strain Gauge and Load Cell Amplifier
• Designed to excite, amplify, and measure the voltage signal from a strain gauge or load cell
• Can accept, full-bridge configuration, external completion resistor for a quarter & half bridge

Infrared Brake Temperature Sensor

To measure the highly transient surface temperature of a brake rotor at multiple points

• Measuring temperature at 16, 8, or 4 points at a sampling frequency of up to 100Hz.
• Temperature Measurement Range, To -20 to 1100˚C.
• Package Temperature Range, Tp -20 to 85˚C.
• Emissivity 0.01 to 1.00(steel = 0.55, carbon = 0.85).

Single-Point IR Temperature Sensor

Temperature measurement of tires, asphalt, belts, and cabin interiors.

• Temperature Measurement Range, To -70 to 380˚C.
• Package Temperature Range ,Tp -40 to 85˚C.
• Sampling Frequency 8Hz.
• Supply Voltage, Vin 5 to 8 V

Tire Temperature & Pressure Monitoring System (TTPMS)

To measure the highly transient surface temperature of a brake rotor at multiple points

• Measure Contact Patch Load Variation (CPLV)using a high-speed (1000Hz)
• Pressure, Range (Absolute) 0 to 5000 mBar
• Internal Temp., Range -40 to 150˚C
• 16-channels temperature
• Supply voltage: 5 to 16V

InfraRed Tire Temperature Sensor

Temperature measurement of tires

• Package Temperature Range ,Tp -20 to 85˚C.
• Number of Channels 16, 8, or 4.
• Sampling Frequency 100, 64, 32, 16, 8, 4, 2 or 1Hz.
• Supply Voltage, Vin 5 to 8 V

Laser Ride Height Sensor (CAN)

To measure ride height with micron-level resolution and sub-milli second response

• Temperature Measurement Range, To -70 to 380˚C.
• Measurement Range30 to 300mm
• Resolution (matte object)< 0.02mm at 30mm< 0.4mm at 300mm
• Temperature Range -10 to 50°C
• Supply Voltage 8 to 32V
